YASONG SLA-FZ7000 100m Crane Laser Anti-Collision System, 80dB Alarm, Dual-Side Monitoring, RS485 Optional
Choose the correct AC110V or AC220V configuration and select either one or two laser sensors before ordering. Confirm whether RS485, switch outputs, or 4–20mA output are required for system integration.
Product Overview
The YASONG SLA-FZ7000 is an industrial crane laser anti-collision system designed to detect obstacles and nearby cranes across a measuring range of 0.5m to 100m. It combines non-contact laser ranging with audible and visual warnings to help operators respond before equipment enters a preset risk zone.
The system supports single- or dual-sensor configurations and can monitor both sides of a rail-mounted crane when equipped with two laser sensors. The main unit displays measured distance and provides an 80dB alarm, while optional RS485, switch, and 4–20mA outputs support connection with compatible control systems.
- 0.5–100m laser detection range with ±2% accuracy
- Less than 0.5s response time for fast distance monitoring
- Single- or dual-side monitoring with 1 or 2 laser sensors
- 80dB audible and visual warning with multi-level distance alerts
- IP54 main unit and IP65 laser sensor for industrial environments
Choose the correct voltage and sensor configuration before ordering. Available configurations include one main unit with one or two laser sensors; communication and output options should also be confirmed for the intended control system.
Key Specifications
Quickly compare the most important details before ordering.
Product Highlights
Key features that help you decide whether this model fits your use.
0.5–100m Laser Detection
The laser sensor measures distances from 0.5m to 100m with ±2% accuracy, providing non-contact obstacle and crane proximity monitoring.
Single or Dual-Side Monitoring
Choose one laser sensor for single-side detection or two sensors for monitoring both sides of the crane through the main control unit.
Fast Multi-Level Warning
The system responds in less than 0.5 seconds and provides audible and visual warnings at configured distance thresholds to give operators additional reaction time.
Industrial Signal Integration
Optional RS485 communication, two-channel switch output with NO and NC contacts, and a 4–20mA analog output support integration with compatible industrial control systems.
Industrial Environment Protection
The main unit is rated IP54 and the laser sensor is rated IP65. Both are specified for operating temperatures from -40°C to 70°C and humidity up to 95% RH.
Full Product Specifications
Detailed specifications for installation, comparison and compatibility checks.
- Product Type
- Laser Anti-Collision System
- Input Voltage
- AC110V / AC220V Options; Laser Sensor: DC12V–DC24V When Used with Main Unit, AC220V for Standalone Use
- Power
- Main Unit: Max. 15W; Laser Sensor: ≤3W
- Sound Level
- 80dB
- Alarm Mode
- Multi-Level Audible and Visual Alarm
- Trigger Mode
- Laser Distance Detection
- Control Mode
- Laser Detection; RS485 Communication Optional
- Work Mode
- Single-Side or Dual-Side Monitoring
- Lighting Mode
- Multi-Level Visual Warning
- Protection Rating
- Main Unit: IP54; Laser Sensor: IP65
- Installation Method
- Wall-Mounted
- Operating Temperature Range
- -40°C to 70°C
- Working Humidity
- ≤95% RH
- Net Weight
- Laser Sensor: 1.0 kg Reference
- Detection Range
- 0.5m–100m
- Induction Angle
- 3°
- Typical Application Scenarios
- Steel Mills, Ports and Terminals, Heavy Manufacturing Plants, Crane Runways, Large Warehouses, Logistics Centers, Power Plants, Hydropower Stations
- Tips
- Choose the correct AC110V or AC220V configuration and select either one or two laser sensors before ordering. Confirm whether RS485, switch outputs, or 4–20mA output are required for system integration.
- Customization
- AC110V / AC220V Options; 1 Main Unit + 1 Laser Sensor or 1 Main Unit + 2 Laser Sensors
Need help choosing the right model?
Tell us your voltage, installation location and how you want the alarm or warning light to work. We will help you check a suitable option before you order.
